Product Characteristics D series digital amplifier offer various power ratings in 4 models from 4x800watt/ch. @ 2 ohm to 4x3570 watts/ ch @ 2 ohm, still maintaining the 1 unit size.
Advantages of high efficiency
Low working temperature, reliability will be improved obviously. The size and weight are only 1/3 of tradition amplifier The cost for transportation, handling, installation will reduce obviously Saving energy, reducing operating costs Environmental protection
Performance overview
1.High efficiency and energy saving, operation cost is low. 2.Compact and light weight , structure is firm. 3. Comply with the safety and EMC standards. 4.90V-260V AC/50-60HZ Wide range power supply. 5. First-class quality, thanks for the components from internationalhigh-end manufacturers. 6. Temperature control fan for quiet operation. 7.Modular design and maintenance is convenient. 8. Very suitable for mobile show. 9. Reasonable design makes you feel relaxed in the process of using.
D series digital amplifier offer various power ratings in 4 models from 4x800watt/ch. @ 2 ohm to 4x3570 watts/ ch @ 2 ohm, still maintaining the 1 unit size.
Advantages of high efficiency
Low working temperature, reliability will be improved obviously.
The size and weight are only 1/3 of tradition amplifier
The cost for transportation, handling, installation will reduce obviously
Saving energy, reducing operating costs
Environmental protection
Performance overview
1. High efficiency and energy saving, operation cost is low.
2. Compact and light weight , structure is firm.
3. Comply with the safety and EMC standards.
4.90V-260V AC/50-60HZ Wide range power supply.
5. First-class quality, thanks for the components from internationalhigh-end manufacturers.
6. Temperature control fan for quiet operation.
7.Modular design and maintenance is convenient.
8. Very suitable for mobile show.
9. Reasonable design makes you feel relaxed in the process of using.
Model
D-500
D-700
D-900
D-1100
Rated Output Power
（THD+N=1%,1kHz continue sine wave, allchannel driving）
8Ω/Stereo
4×300W
4×500W
4×1000W
4×1500W
4Ω/Stereo
4×465W
4×850W
4×1700W
4×2550W
2Ω/Stereo
4×800W
4×1445W
4×2890W
4×2750W
16Ω/Bridge
2×600W
2×1000W
2×2000W
2×3000W
8Ω/Bridge
2×900W
2×1700W
2×3400W
2×5100W
4Ω/Bridge
4×1550W
2×2890W
2×5780W
2×7140W
Output RMS voltage[THD+N=1%,1kHz]
48.7V
63.2V
89.4V
109.5V
Slew rate[ 1kHz,low-pass filter bypassed]
50V/uS
Sensitivity(Rated Power,1kHz)
Selectable
35dB,32dB,29dB.26dB
Selectable
38dB,35dB,32dB.29dB
Selectable
41dB,38dB,35dB.32dB
THD+N(10% Rated Power,typical]
0.01%
IMD-SMPTE(10% Rated Power,typical)
0.01%
DIM30(10%Rated Power,typical]
0.01%
Cross-talk
(20Hz-1kHz,below Rated Power]
≥90dB
Input impedance
20kΩ(Balance)，10kΩ(Unbalance
Damp factor[8Ω,20Hz-200Hz)
≥3537 （8Ω,20Hz-200Hz）
SNR
≥104dB
≥105dB
≥109dB
≥110dB
Main Power
90~260VAC,50~60Hz
Protection
Under voltage, DC,Over temperature, Over load limiter, Short protection.
