Product Characteristics MA series is the professional two-channel Analog amplifier used ClassAB amplification circuit with RMS equal, which offer more efficiency,more power and less heat. It is offer various power ratings in 5 modelsfrom 2x530watt/ch. @ 4 ohm to 2x1350 watts/ch @ 4 ohm. Features 1.Professional aluminum metal cabinet shows its stability,reliability, andfascination. 2.Advanced output AB-class circuit ,ensuring perfect sound qualitycondition, and the power and efficiency are higher than the conventional AB-classcircuit 3.Effective heat dissipation system, comprising a high surface area of the heat sink, a pair of dual cooling fan to ensurea rapid and reliable coolin.Good quality and rugged construction for most of the expansion of applications are idealpower amplifier Al amplifier are similar in operation, the manual applies to all modes. The manual contains veryimportant information, so in the connection or operation of your amplifier carefully read the manual. 4.The unit has consummate working staus indications including, vou can be clear at aalance of the working statusthrough the LED indicator in the front panel of the amplifier, the letthe operation more easily. 5、Perfect Protection Circuit Design: A. Soft start. B.Over temperature protection. C.Over load protection. D. Short Circuit Limited Protection.E. AC Line fuseF. Limiter Protection G. DC protection. H.Thermal cut.
MA series is the professional two-channel Analog amplifier used ClassAB amplification circuit with RMS equal, which offer more efficiency,more power and less heat. It is offer various power ratings in 5 modelsfrom 2x530watt/ch. @ 4 ohm to 2x1350 watts/ch @ 4 ohm.
Features
1. Professional aluminum metal cabinet shows its stability,reliability, andfascination.
2. Advanced output AB-class circuit ,ensuring perfect sound qualitycondition, and the power and efficiency are higher than the conventional AB-classcircuit
3. Effective heat dissipation system, comprising a high surface area of the heat sink, a pair of dual cooling fan to ensurea rapid and reliable coolin.Good quality and rugged construction for most of the expansion of applications are idealpower amplifier Al amplifier are similar in operation, the manual applies to all modes. The manual contains veryimportant information, so in the connection or operation of your amplifier carefully read the manual.
4.The unit has consummate working staus indications including, vou can be clear at aalance of the working statusthrough the LED indicator in the front panel of the amplifier, the letthe operation more easily.
5、Perfect Protection Circuit Design:
A. Soft start.
B.Over temperature protection.
C.Over load protection.
D. Short Circuit Limited Protection.E. AC Line fuseF. Limiter Protection
G. DC protection.
H.Thermal cut.
Model
MA-600
MA-1200
MA-2400
MA-3600
MA-5000
Output
Power
(EIA 1KHZ 1% THD)
Stereo
8Ω
350W×2
450W×2
550W×2
700W×2
900W×2
4Ω
530W×2
680W×2
830W×2
1050W×2
1350W×2
Bridge
8Ω
1060W
1360W
1660W
2100W
2700W
Output Connections
Binding
Speakon & Binding
Frequency Response
20Hz-20KHz,±0.5dB
20Hz-20KHz,-0.5dB
Input Sensitivity
0.77V
Input Impedance
20KΩ/Balanced,10KΩ/un-Balanced
S/N Ratio
= 95dB
= 98dB
THD
= 0.03%
=0.05%
Crosstalk @ Rated Output/8Ω/1KHz
>70dB
>62dB
Damping Factor/ 8Ω/1KHz
>240
>280
Slew Rate
15V/uS
Protection
Soft Start, Short Circuit, Limiter, DC Fault,AC Line Fuse, Thermal Cut
